Home Products Top Bend LINIO NEON 1617 TV (IP67)
/
LINIO NEON 1617 TV (IP67)

100~300 lumen outputs·Static white


▪  Max run length up to 91.8ft (28m) from single power feed

▪  Field cuttable & joinable

▪  Low voltage DC24V

▪  100~300 lumen outputs

▪  IP67 rated, ideal for indoor and outdoor uses

▪  5 years warranty



Inquiry
Download
Spec Sheet - LINIO NEON 1617 TV (Rev.4-Apr-25)
IES - LINIO NEON 1617 TV
Install Manual - LINIO NEON 1617 TV SERIES (Rev.2024-10-15) - US
Specify your products
Product Code:
LN1617TV
-
W7
-
24
-
-
-
-
-
-
-
-
Copy
Reset
1. Series
LN1617TV
2. Environment
W7-Wet (IP67)
3. Voltage
24-DC24V
4. Temp./Color
22-2200K
27-2700K
30-3000K
35-3500K
40-4000K
53-5300K
5. Power
146-1.46W
293-2.93W
439-4.39W
6. End Cap
IJ-Injected end cap (IP67)
IJC-Clear injected end cap (IP67)
SEC-Silicone end cap (IP67)
MEC1-Mechanical end cap with screws (IP67)
7. Left Feed Entry (A)
F-Front
B-Bottom
S-Side
C-Closed
J-Jumper
8. Left Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
9. Right Feed Entry (A)
F-Front
B-Bottom
S-Side
C-Closed
J-Jumper
10. Right Feed Entry (B)
OW-Open wire 3.28'
MC-Male connector with 0.98' cable
FC-Female connector with 0.98' cable
NA-Only for Closed Feed Entry
11. Length (ft)
* Customizable—Consult Factory
Technical specifications

Series: LN1617TV


Temp./Color

1.46W/ft

2.93W/ft

4.39W/ft

2200K

115

202

291

2700K

118

209

301

3000K

126

217

318

3500K

133

234

336

4000K

133

233

335

5300K

126

220

317


Compatible drivers
KVD Series (0-10V Dimming)
KVD Series (0-10V Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Dimming options: 0-10V/1-10V/Potentiometer/10V PWM

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Built-in active PFC

• Protection: short circuit/over load/over heat

• 0-100% dimmable with dimmer
KVG Series (Triac/0-10V Dimming)
KVG Series (Triac/0-10V Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• 5 in 1 dimmable: Triac/0-10V/1-10V/Potentiometer/10V PWM

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
KVF Series (Phase cut/Triac Dimming)
KVF Series (Phase cut/Triac Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Dimming options: Triac/Phase/ELV/MLV

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Load: 10-100%

• Protection: short circuit/over load/over heat

• Flicker-free
KV Series (Non Dimming)
KV Series (Non Dimming)

30W/60W/96W/150W/200W/300W, UL-listed, 24V


• Non-dimmable

• UL-listed

• Constant Voltage Driver

• Universal Input: 100-277VAC

• Protection: short circuit/over load/over heat
Related accessories
Male & Female Connector
Male & Female Connector

IP67, 2/3/4/5/6 pin
Extension Male & Female Connector
Extension Male & Female Connector

IP67, 2/3/4/5/6 pin
